The Dakota Digital Universal Speedometer Signal Interface – ELA-SGI-5 delivers unmatched versatility by combining the functions of three calibration tools into one compact module. Designed for modern drivetrain swaps, custom builds, and performance applications, the SGI-100BT allows you to adjust, split, and recalibrate electronic speed signals with precision. It also supports tachometer calibration and even generates gas-style tach signals for diesel conversions, making it an essential tool for accurate instrumentation.

With wide adjustment capability, multiple output options, and compatibility with a variety of sensors, this interface ensures your speedometer and tachometer read correctly—no matter your transmission, tire size, or engine setup. Bluetooth connectivity provides easy programming through a mobile app, while onboard buttons and an LED display offer a convenient alternative for setup without a smartphone.

Key Features

• Combines speed signal calibration, tach calibration, and diesel_swap tach generation in one unit

• Speed signal adjustment range from 25% to 400%

• Multiple speed outputs for feeding several devices simultaneously

• Built-in electronic pull-up; accepts high or low voltage inputs

• Tach settings for 1–16 cylinders with selectable 5V or 12V signal

• Diesel-compatible outputs for 4, 6, or 8-cylinder tachometers

• Reads from flywheel sensors, timing gear sensors, or alternator W_terminals

• Bluetooth-enabled for app-based programming and setup

• Onboard buttons and LED display for manual configuration

• Not compatible with ABS sensors or most ’86+ European or ’96+ Jeep tachometers
